Copper wire drawing machines do not share one fixed internal layout. Designs differ clearly by application. Here are four common types and their key internal structures.
Cable copper wire drawing machine
Base support: a worktable that serves as the mounting base for the whole machine.
Drawing and forming: a removable tapered sleeve and a first cooling box. The cooling box contains a first cooling pool for saponified solution. The sleeve bore diameter narrows along the copper wire travel direction, which draws and shapes the wire. The cooling box has a discharge port.
Cleaning aid: a scraper with a scraping section and a retention groove. It touches the lower circumference of the guide wheel and scrapes drawing fluid off the copper wire.
Wire guide: a rotating guide wheel below the discharge port, with its axis perpendicular to the copper wire transport direction. It works with a connecting shaft, a first guide roller, two second guide rollers, and a guide piece to keep the wire path aligned.
Copper stranded wire production drawing machine
Mounting and support frame: a channel frame and a base. A pay-off stand and a take-up stand are mounted on opposite sides of the base.
Drawing assembly: a first slot on the channel frame for a plug-in drawing die.
Lubrication and cleaning: a hollow plate in a second slot, with a sponge block inside. The side near the pay-off stand connects to a first conduit with a first rubber scraper ring. This cleans impurities from the copper wire surface in advance.
For drawing dies, guide wheels, and related wear parts, Hansheng Automation can machine custom components from customer drawings in single pieces or small batches.
Pure copper wire production drawing machine
Frame body: multiple drawing dies evenly arranged on top.
Annealing and cooling: an annealing cooling chamber on one side of the frame. Two sets of heating wires are installed at the top inside. A temperature sensor monitors temperature in real time. A first fan between the heating wires helps heat circulation. A purification box with a filter on the outlet side treats annealing exhaust gas.
Raw material path: coarse copper wire passes through each drawing die in sequence for drawing.
Intelligent copper wire drawing machine
Modular drawing units: multiple drawing seats evenly spaced on the upper machine base. Each seat has a drawing fluid tank and a die slot from left to right, separated by a partition.
Active cleaning structure: a cylinder cavity with a drainage inner cover. After the constant speed motor starts, it moves in a circle. Centrifugal force discharges the mixed liquid and creates negative pressure to help drawing fluid flow, which improves cleaning.
Supporting pay-off device, pulling and drive components complete fully automated drawing.
Our precision custom machining is not limited to copper wire drawing machines. Hansheng Automation also produces non-standard parts for wire and cable equipment, spring manufacturing machinery, welding wire lines, filling machinery, tobacco packaging machinery, medical device production equipment, yacht hardware, and RC car components. We work from customer drawings for single pieces or small batches. The focus stays on precision parts machining and delivery, which keeps maintenance and replacement flexible across different industries.
