A large-scale waste sorting plant needs to be equipped with professional tools and equipment across five major categories: pre-processing, mechanical sorting, manual sorting, resource recovery, and safety protection. These cover the full workflow of material dismantling, sorting, transfer, harmless treatment, and operational safety.
1. Pre-Processing Equipment and Tools
Heavy-duty loaders or wheeled grab loaders: used for moving and stacking bulk waste within the plant, suitable for loading and transferring municipal solid waste and bulky waste. Typical rated loads range from 3 to 10 tons.
Crusher series: including jaw crushers, hammer crushers, and shear crushers, used to break down bulky waste such as discarded furniture and appliance housings, as well as compacted waste blocks, reducing material size for subsequent sorting processes.
Integrated magnetic separation feeders: combine uniform feeding with preliminary ferromagnetic material separation to prevent iron impurities from damaging downstream precision sorting equipment.
Trommel screens: classify crushed waste by particle size, separating fine and coarse fractions to match the material specifications required by different sorting processes.
2. Mechanical Sorting Equipment and Tools
Air separators: use airflow density differences to separate light materials such as plastic film and paper fibers from heavy materials such as bricks, stones, and metal blocks.
Eddy current separators: precisely separate non-ferrous metals such as copper, aluminum, and zinc, serving as core equipment for resource recovery from mixed waste.
Ballistic separators: use differences in material bouncing characteristics to separate soft elastic materials from hard brittle materials, for example distinguishing plastics from glass fragments.
Optical sorters: based on differences in optical properties, precisely sort single-material plastics, glass, and other materials, with sorting accuracy typically reaching 92% to 98%.
Belt conveyor systems: including main conveyor lines, inclined conveyors, and telescopic conveyors, enabling continuous material transfer between sorting stages.
3. Manual Sorting Support Tools
Height-adjustable sorting workstations: equipped with anti-slip tabletops, adapted to operators of different heights for precise sorting of impurities and recyclables.
Handheld sorting tools: including anti-slip work gloves, anti-static tweezers, small picking pliers, and explosion-proof handheld flashlights for use in dimly lit work areas.
Temporary transfer tools: manual hydraulic pallet trucks and lift platform carts for quickly transferring manually sorted materials to temporary storage areas.
4. Resource Recovery Support Tools
Horizontal hydraulic balers: compress sorted recyclables such as plastics, paper, and textiles into bales, increasing storage and transport density and reducing logistics costs.
Metal briquetting machines: compact sorted ferrous and aluminum metal scrap into blocks for centralized recycling.
Food waste treatment equipment: for plants handling kitchen waste, this includes food waste crushers, oil-water separators, and aerobic composting units to achieve harmless treatment of organic waste.
Hazardous waste temporary storage tools: including sealed explosion-proof storage drums and leak-proof spill pallets for temporary storage of hazardous waste such as waste batteries and waste paint cans.
5. Safety Protection Tools and Equipment
Personal protective equipment: safety helmets, anti-slip work shoes, KN95 or higher dust masks, gas masks for areas with organic volatiles, and high-visibility reflective work vests.
Operational safety facilities: section guardrails, emergency stop button groups, portable gas detectors for confined spaces and organic exhaust areas, fire hydrants, dry powder fire extinguishers, and emergency lighting systems.
Equipment inspection tools: portable thermometers, torque wrenches, and equipment inspection toolkits for routine maintenance and troubleshooting.
