The main differences between a car-bottom furnace and a tunnel furnace come down to operation logic, application, production efficiency, and cost structure. The two are not direct substitutes for each other. Selection starts with part size, batch size, process cycle, and capital budget.
Working logic
A car-bottom furnace runs in batch mode. The furnace body is fixed. Parts are loaded onto a dedicated car or bogie, pushed into the heating chamber for heating or heat treatment, and then pulled out for unloading. From customer drawings, Hansheng Automation can machine non-standard parts for car-bottom furnaces, including heat-resistant trays, furnace bottom plates, car rails, and door seals, in single pieces or small batches.
A tunnel furnace runs continuously. Its furnace body is a long tunnel. Conveyor chains, roller lines, or similar handling systems move parts at a steady speed through preheating, heating, and cooling zones. The furnace itself does not move during production.
Applications
Car-bottom furnaces suit small batches, high-mix work, and large parts, such as heavy machinery gears, large castings, and forgings for quenching and tempering. They allow a higher upper limit for part size and weight per load and make batch changes easier.
Tunnel furnaces suit high-volume, standardized small parts, such as hardware quenching, food baking, and electronic component drying. They provide higher output per hour and fit flow-line production.
Parameters and cost
The batch size of a car-bottom furnace is limited by car dimensions. Heat-up and cool-down cycles are long. Energy loss is concentrated in opening and closing the furnace for each cycle. It fits non-continuous production, and equipment purchase cost is usually lower.
A tunnel furnace has a longer body, more precise zone temperature control, and can run 24 hours a day. Energy use per part is lower, but equipment investment and floor space are higher.
Operating flexibility
A car-bottom furnace can be paused at any time to change part type and process parameters. It offers greater freedom for adjustment.
Once a tunnel furnace starts, it needs stable conveyor speed and furnace temperature. Process changes often require a full-line stop, so flexibility is lower.
