A paper box pressing mechanism handles folding, pressing, and forming. Several types are available for different applications and needs. Here are four common designs.
Pressing mechanism with a sealing flap folding device
It uses two pressing plate devices to fold the sealing flaps in sequence. It also has a pressing plate device to press the folded sealing flaps and a side panel folding device.
Benefits: it presses the box flat, reduces floor space, simplifies dimensions, cuts cost, and improves production efficiency.
Pressing mechanism on a paper box forming machine
The first servo motor drives a gear and rack. This moves a lift rod and lift seat. It controls four pressing molds that correspond to the four corners of the box.
Benefits: simple structure and reasonable design. The pressing molds lift and lower steadily. The box is pressed steadily into the forming mold.
When pressing plates, molds, or gear racks need replacement, we machine these precision parts from customer drawings in single pieces or small batches.
Pre-pressing mechanism for paper box printing
It consists of a pre-pressing base and a pre-pressing upper plate. The upper plate position is adjusted through an assembly screw and support frame.
Benefits: it helps adjust pre-pressing and is easier to use.
Paper box pressing mechanism on continuous high-speed cartoning machines
It includes an auxiliary disc, transmission cavity, movable cavity, drive gear, threaded rod, contraction rod, and pressing disc.
Benefits: it adapts to square boxes of various depths and sizes. Practical for many applications.
Selection depends on the application, box type, and production needs. Consider all factors together.
