Internal mixer rotor end face seals mainly use two structures: mechanical seals and labyrinth seals. Mechanical seals are the mainstream choice for modern high-efficiency internal mixers. Hansheng Automation can machine dynamic rings, stationary rings, springs, O-ring grooves, and carbide mating rings from customer drawings, in single pieces or small batches.
1. Mechanical seal
Structure: It consists of a dynamic ring, a stationary ring, a spring, and an auxiliary sealing ring such as an O-ring. The dynamic ring rotates with the rotor. The stationary ring is fixed to the frame. Spring force keeps the two ring faces in tight contact for sealing.
Key parameters:
Face pressure: usually 0.3 to 0.6 MPa
Spring pressure: 0.05 to 0.2 MPa
Linear speed: ≤20 m/s for high-viscosity compound conditions
Leakage rate: <10 mL/h, as required by GB/T 14211-2019
Applications: high temperature ≤200 °C, high pressure ≤2.5 MPa, and precision mixing conditions that require zero leakage, such as medical and food-grade rubber production.
2. Labyrinth seal
Structure: Multiple stages of tortuous clearance between the rotor and seal cover create fluid resistance for sealing. It is a non-contact seal with no mechanical wear.
Features:
Allows larger axial movement: ±2 mm
Strong resistance to particulate impurities
Higher leakage: about 200 to 500 mL/h
Suitable for low speed and room temperature conditions
3. Comparison
| Feature | Mechanical seal | Labyrinth seal |
|---|---|---|
| Sealing principle | Face contact sealing | Clearance throttling sealing |
| Leakage | <10 mL/h | 200 to 500 mL/h |
| Temperature resistance | ≤200 °C | ≤120 °C |
| Allowable axial movement | ±0.5 mm | ±2 mm |
| Maintenance interval | 6 to 12 months, replace dynamic ring | 24 months or more, cleaning only |
| Applicable pressure | ≤2.5 MPa | ≤0.8 MPa |
4. Selection advice
Polymer mixing, such as TPE and TPU: prefer a double mechanical seal with a heat transfer oil flushing system to prevent material carbonization.
Carbon black filled compound: use a mechanical seal with carbide mating rings. Wear resistance increases more than 3 times. We can machine carbide mating rings and other wear parts from drawings.
Low speed large internal mixer, rotor speed <30 rpm: a labyrinth seal plus exhaust recovery device can be used.
Note: When replacing seals, check rotor axial movement. It must be ≤0.3 mm. If out of tolerance, adjust the thrust bearing. Otherwise, the mechanical seal will wear abnormally.
