What is a Right Angle Gearbox?
A right angle gearbox is a The output and input shafts in a right-angle gearbox cross at a 90-degree angle. With rotation, this arrangement lets torque be transmitted from one axis to a perpendicular axis.
Compact right-angle design of Hansheng PGHR115 Right Angle Planetary Gearboxes guarantees great torque and accuracy. Continuous backlash correction technology in these gearboxes guarantees low backlash all through their lifetime.
A high-precision, compact design right angle planetary gearbox widely used in high demand industrial fields such as automation, robotics, packaging machinery, and CNC equipment. It combines the advantages of right angle transmission and planetary gearbox, providing high torque output, high efficiency, and reliable performance.
Large crossed roller bearings directly handle heavy loads and give great moment stiffness, acting as output flanges. The PGHR Series Right Angle Planetary Gears come in flanged outputs, smooth output shafts, or shafts with keyed and tapped centre holes.
What are the features of this product?
PGHR115 Right Angle Planetary Gearboxes use precision machined planetary gears and right angle gears with a gearbox accuracy of 6 arc minutes, therefore satisfying the rigorous criteria for positioning accuracy in uses like industrial robots and automated manufacturing lines.
Thanks to its planetary gear transmission system, PGHR115 can offer up to 1000Nm of torque output while keeping a small design that lets it give strong power transmission capabilities in constrained area.
High efficiency: This gearbox can keep effective operation even under high-speed and high load conditions, so lowering energy loss and raising the general system efficiency. Its gearbox efficiency is as high as 95%.
PGHR115 uses a right angle design, which is especially appropriate for mechanical equipment needing a simplified layout and can help to efficiently reduce installation space. Its modular architecture also makes it simple to combine with different motors and equipment since it lets one arrange it however desired.
Low noise and low backlash: The helical gear design optimises the smooth gear mesh, so the running noise is less than 65dB. Furthermore fit for precision positioning uses is its back clearance design, which has been carefully tuned to manage the back clearance within 3-5 arc minutes.
Product advantages
PGHR115 provides adaptable solutions for many industrial uses since it offers a spectrum of reduction ratios from 3:1 to 100:1 to satisfy the speed and torque needs under diverse running situations.
High-strength alloy steel material makes up this gearbox, which has undergone surface treatment techniques including carburising and quenching, which have great wear resistance and high fatigue resistance, so ensuring that it maintains a long service life in demanding surroundings. Low maintenance design lowers running expenses and increases equipment production effectiveness.
PGHR115 is extensively relevant to numerous kinds of industrial equipment since it supports several installation techniques and is compatible with several servo motors and stepper motors.
With its great precision, high efficiency, and broad application possibilities, PGHR115 Right Angle Planetary Gearbox offers overall outstanding answers for industrial automation and precision gearbox applications.
Technical Parameter
Dimensions: PGHR115 has a 115mm flange and a small construction fit for restricted space equipment installation requirements. Usually depending on the particular arrangement and reduction ratio, weight falls between 8-12 kg.
From 3:1 to 100:1, optional reduction ratios give a large variety of choices to satisfy different torque and speed needs. Typical reduction ratios run 3:1, 5:1, 10:1, 20:1, 30:1, etc.
Efficiency: While in the second stage gearbox the efficiency is about 92%, guaranteeing minimum power loss, in the first stage gearbox the efficiency is as high as 95%.
Reduced ratio and input speed will allow the rated output torque to vary between 220Nm and 300Nm. This value qualifies for uses requiring high torque, such those of heavy-duty automation tools and robots. Designed to handle significant load impacts in a short period of time, maximum instantaneous torque ranges up to three times the specified torque.
Low backlash design: The standard backlash is between 3-5 arc minutes; high-precision models can be regulated within < 3 arc minutes, fit for working situations with very high precision needs, including CNC machining centres and precision robot systems.
Up to 6000 RPM, maximum input speed fits for circumstances driven by high-speed servo motors or stepper motors. Operating below 3000 RPM is advised as recommended input speed will help to guarantee gearbox lifespan.
Noise level: Particularly fit for locations with rigorous noise control needs, such electronic assembly or medical equipment, the noise level during operation is less than 70dB.
radial and axial loads:
Maximum radial load: 2500N allows one to withstand. Maximum axial load: It guarantees steady operation under heavy loads by being able to withstand 3000N.
Compatibility with several servo motors and stepper motors, this gearbox offers several installation techniques including flange installation and shaft installation. Designed either as solid or hollow, the output shaft supports a keyway or clamping connection.
